UA9637ACDRE4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 UA9637 Tape & Reel (TR) RS422RS423 interface receiver 5V 50mA 72.603129mg 10Mbps
PDF
/
Inventory: 1939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 72.603129mg
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Type Receiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology BIPOLAR
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number UA9637
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Nominal Supply Current 50mA
Data Rate 10 Mbps
Differential Output NO
Protocol RS422, RS423
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 0/2
Receiver Hysteresis 70mV
Number of Drivers 0
Supply Voltage1-Nom 5V
Number of Receivers 2
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
