TSB41AB1PHPG4
RoHS
RoHS compliant
RoHS compliantPackage 48-PowerTQFP
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 TSB41AB1 Tray IEEE 1394 interface driver 3.3V 48mA 134.490138mg 400Mbps
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.73815
≥1 USD $0.73815
≥10 USD $0.6061
≥100 USD $0.5871
≥500 USD $0.5681
≥1000 USD $0.5491
Inventory: 8412
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 7mm
Length 7mm
Height 1.2mm
Technical
Number of Transmitters 1
Supply Voltage1-Nom 3.3V
Duplex Half
Receiver Number of Bits 2
Dual Supply Voltage 3.3V
Min Dual Supply Voltage 2.7V
Driver Number of Bits 2
Number of Drivers/Receivers 2/2
Max Dual Supply Voltage 3.6V
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol IEEE 1394
Differential Output YES
Data Rate 400 Mbps
Nominal Supply Current 48mA
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number TSB41AB1
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Technology CMOS
Subcategory Line Driver or Receivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Weight 134.490138mg
Number of Pins 48
Surface Mount YES
Package / Case 48-PowerTQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
