TRSF3243IDWR
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant SCHMITT TRIGGER GULL WING Full Transceiver -40C~85C 1Mbps 730.794007mg 0.000001A
PDF
/
Buying Options
Total Price: USD $2.12
Unit Price: USD $2.12135
≥1 USD $2.12135
≥10 USD $1.74135
≥100 USD $1.68625
≥500 USD $1.6321
≥1000 USD $1.57795
Inventory: 1546
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Weight 730.794007mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Transceiver
Subcategory Line Driver or Receivers
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 5
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TRSF3243
Pin Count 28
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Supply Current-Max 1mA
Data Rate 1Mbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 3/5
Duplex Full
Receiver Hysteresis 500mV
Number of Drivers 3
Output Low Current-Max 0.0016A
Number of Receivers 5
Out Swing-Min 10 V
High Level Input Current-Max 0.000001A
Dimensions
Length 17.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
