TRSF3238CDW
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 TRSF3238 Tube RS232 interface receiver 5.5V 0.000001A 730.794007mg 1Mbps
PDF
/
Inventory: 6813
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 17.9mm
Technical
High Level Input Current-Max 0.000001A
Out Swing-Min 10 V
Output Low Current-Max 0.0016A
Number of Drivers 5
Interface Standard EIA-232
Receiver Hysteresis 300mV
Duplex Full
Receiver Number of Bits 3
Number of Drivers/Receivers 5/3
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Data Rate 1Mbps
Supply Current-Max 2mA
Operating Supply Voltage 5.5V
Qualification Status Not Qualified
Pin Count 28
Base Part Number TRSF3238
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 5
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Subcategory Line Driver or Receivers
Type Transceiver
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 730.794007mg
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
