TRS3238EIDBR
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 TRS3238 Tape & Reel (TR) RS232 interface driver 300mV 2mA 208.397344mg 400kbps
PDF
/
Buying Options
Total Price: USD $10.09
Unit Price: USD $10.0928
≥1 USD $10.0928
≥10 USD $8.28115
≥100 USD $8.02275
≥500 USD $7.7634
≥1000 USD $7.505
Inventory: 1260
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Number of Pins 28
Weight 208.397344mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Transceiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 3
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TRS3238
Pin Count 28
Qualification Status Not Qualified
Nominal Supply Current 2mA
Logic Function Receiver
Data Rate 400kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 5/3
Duplex Full
Receiver Hysteresis 300mV
Number of Drivers 5
Number of Transceivers 1
Supply Voltage1-Nom 3.3V
Number of Receivers 3
Dimensions
Height 2mm
Length 10.2mm
Width 5.3mm
Thickness 1.95mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
