TRS3237EIPW

Texas Instruments
RoHS
RoHS RoHS compliant
Package 28-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description ROHS3Compliant SCHMITT TRIGGER GULL WING Full Transceiver -40C~85C 1Mbps 117.508773mg 2mA
PDF
/
Buying Options
Total Price: USD $2.26
Unit Price: USD $2.25625
≥1 USD $2.25625
≥10 USD $1.85155
≥100 USD $1.7936
≥500 USD $1.73565
≥1000 USD $1.6777
Inventory: 1139
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 4.4mm
Length 9.7mm

Technical

Number of Receivers 3
Number of Transceivers 1
Number of Drivers 5
Receiver Hysteresis 500mV
Duplex Full
Number of Drivers/Receivers 5/3
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Data Rate 1Mbps
Logic Function Receiver
Nominal Supply Current 2mA
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 28
Base Part Number TRS3237
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 3.3V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Weight 117.508773mg
Number of Pins 28
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
