TRS3232EIDW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 TRS3232 Tube ALSO OPERATES AT 5V SUPPLY interface driver 5V 1mA 420.395078mg 250kbps
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.2088
≥1 USD $2.2088
≥10 USD $1.98352
≥100 USD $1.87088
Inventory: 159
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Supply Voltage1-Nom 3.3V
Number of Transceivers 1
Number of Drivers 2
Receiver Hysteresis 300mV
Duplex Full
Receiver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Output Polarity INVERTED
Differential Output NO
Data Rate 250kbps
Logic Function Receiver
Nominal Supply Current 1mA
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 16
Base Part Number TRS3232
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 3.3V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Additional Feature ALSO OPERATES AT 5V SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 420.395078mg
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
