TRS3232CPWG4
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 Rail/Tube ALSO OPERATES AT 5V SUPPLY Nickel/Palladium/Gold (Ni/Pd/Au) interface receiver 5.5V 1mA 61.887009mg 300ns
PDF
/
Buying Options
Total Price: USD $2.07
Unit Price: USD $2.073901
≥1 USD $2.073901
≥10 USD $1.956505
≥100 USD $1.845765
≥500 USD $1.741288
≥1000 USD $1.642724
Inventory: 1525
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 4.4mm
Length 5mm
Technical
Number of Receivers 2
Supply Voltage1-Nom 3.3V
Simplex/Duplex Full Duplex
Number of Transceivers 1
Driver Number of Bits 2
Interface IC Type LINE TRANSCEIVER
Input Characteristics SCHMITT TRIGGER
Output Polarity TRUE
Differential Output NO
Data Rate 250 kbps
Logic Function Receiver, Transceiver
Propagation Delay 300 ns
Nominal Supply Current 1mA
Number of I/O 8
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Temperature Grade COMMERCIAL
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Line Driver or Receivers
Additional Feature ALSO OPERATES AT 5V SUPPLY
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Rail/Tube
Physical
Weight 61.887009mg
Number of Pins 16
Package / Case TSSOP
Mount Surface Mount
