TRS3232CDW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant SCHMITT TRIGGER GULL WING Full Transceiver 0C~70C 3.3/5V 250kbps 420.395078mg
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2445
≥1 USD $1.2445
≥10 USD $1.02125
≥100 USD $0.9899
≥500 USD $0.9576
≥1000 USD $0.9253
Inventory: 1589
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Weight 420.395078mg
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Transceiver
Additional Feature ALSO OPERATES AT 5V SUPPLY
Subcategory Line Driver or Receivers
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 3.3V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TRS3232
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 3.6V
Power Supplies 3.3/5V
Nominal Supply Current 1mA
Data Rate 250kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 2/2
Receiver Number of Bits 2
Duplex Full
Receiver Hysteresis 300mV
Number of Drivers 2
Out Swing-Min 10 V
High Level Input Current-Max 0.000001A
Dimensions
Length 10.3mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
