TRS3223IPW
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant SCHMITT TRIGGER GULL WING Full Transceiver -40C~85C 3.3/5V 250kbps 76.997305mg
PDF
/
Inventory: 2094
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Number of Pins 20
Weight 76.997305mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Type Transceiver
Additional Feature ALSO OPERATES AT 5V SUPPLY
Subcategory Line Driver or Receivers
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TRS3223
Pin Count 20
Qualification Status Not Qualified
Operating Supply Voltage 3.6V
Power Supplies 3.3/5V
Nominal Supply Current 1mA
Data Rate 250kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 2/2
Receiver Number of Bits 2
Duplex Full
Receiver Hysteresis 500mV
Number of Drivers 2
Output Low Current-Max 0.0016A
Out Swing-Min 10 V
High Level Input Current-Max 0.000001A
Dimensions
Length 6.5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
