TRS222CDWG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description ROHS3Compliant SCHMITT TRIGGER GULL WING Full Transceiver 0C~70C 5V 200kbps 3500ns
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 1177
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Number of Pins 18

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 18
ECCN Code EAR99
Type Transceiver
Subcategory Line Driver or Receivers
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Supply Voltage 5V
Base Part Number TRS222
Pin Count 18
Operating Supply Voltage 5.5V
Power Supplies 5V
Nominal Supply Current 10mA
Logic Function Receiver, Transceiver
Data Rate 200kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 2/2
Receiver Number of Bits 2
Duplex Full
Receiver Hysteresis 500mV
Number of Drivers 2
Number of Transceivers 1
Transmit Delay-Max 3500 ns
High Level Input Current-Max 0.00004A

Dimensions

Width 7.5mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
