THS6182DWRG4
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant DIFFERENTIAL GULL WING Driver interface receiver -40C~85C +-5/+-15V 450V/mus 7.5mm
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.02325
≥1 USD $4.02325
≥10 USD $3.30125
≥100 USD $3.19865
≥500 USD $3.0951
≥1000 USD $2.99155
Inventory: 991
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Type Driver
Voltage - Supply 10V~30V ±5V~15V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 12V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number THS6182
Pin Count 20
Qualification Status Not Qualified
Power Supplies +-5/+-15V
Number of Channels 2
Slew Rate 450 V/μs
Differential Output NO
Protocol DSL
Input Characteristics DIFFERENTIAL
Number of Drivers/Receivers 1/0
Driver Number of Bits 2
Interface Standard GENERAL PURPOSE
Negative Supply Voltage-Nom -12V
Dimensions
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
