THS6043IPWPR
RoHS
RoHS compliant
RoHS compliantPackage 14-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 THS6043 Tape & Reel (TR) ALSO OPERATES AT 10V TO 30V SINGLE SUPPLY interface driver 16.5V 16.4A 58.003124mg 59dB
PDF
/
Buying Options
Total Price: USD $5.94
Unit Price: USD $5.93845
≥1 USD $5.93845
≥10 USD $4.87255
≥100 USD $4.72055
≥500 USD $4.5676
≥1000 USD $4.4156
Inventory: 1671
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 14-PowerTSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 14
Weight 58.003124mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
ECCN Code EAR99
Type Driver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature ALSO OPERATES AT 10V TO 30V SINGLE SUPPLY
Max Power Dissipation 3.3W
Technology BIPOLAR
Voltage - Supply 5V~15V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 12V
Base Part Number THS6043
Pin Count 14
Number of Channels 2
Nominal Supply Current 16.4A
Max Supply Current 16.4A
Slew Rate 1400 V/μs
Common Mode Rejection Ratio 59 dB
Bandwidth 120MHz
Gain Bandwidth Product 120MHz
Differential Output NO
Protocol DSL
Input Characteristics DIFFERENTIAL
Number of Drivers/Receivers 2/0
Driver Number of Bits 2
Dual Supply Voltage 16.5V
Interface Standard GENERAL PURPOSE
Input Bias Current 12μA
Negative Supply Voltage-Nom -12V
Max I/O Voltage 21mV
Supply Voltage1-Nom 12V
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
