SN75LVDS050DRG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant DIFFERENTIAL GULL WING Full Transceiver 0C~70C 3.3V 155Mbps 6ns
PDF
/
Inventory: 6602
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
High Level Input Current-Max 0.00002A
Out Swing-Min 0.247 V
Output Low Current-Max 0.008A
Transmit Delay-Max 6 ns
Receive Delay-Max 6 ns
Interface Standard EIA-644; TIA-644
Duplex Full
Receiver Number of Bits 2
Driver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics DIFFERENTIAL
Protocol LVDS
Differential Output YES
Data Rate 155Mbps
Logic Function Receiver
Supply Current-Max 20mA
Power Supplies 3.3V
Qualification Status Not Qualified
Pin Count 16
Base Part Number 75LVDS050
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
HTS Code 8542.39.00.01
Type Transceiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
