SN75LBC786DW
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
TOTEM-POLE INVERTED ROHS3Compliant DIFFERENTIAL SCHMITT TRIGGER Transceiver 0C~70C +-12V 1000ns 17.9mm
PDF
/
Buying Options
Total Price: USD $32.17
Unit Price: USD $32.173686
≥1 USD $32.173686
≥10 USD $30.35253
≥100 USD $28.634465
≥500 USD $27.013644
≥1000 USD $25.484573
Inventory: 1541
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Transceiver
Additional Feature LOOP BACK
HTS Code 8542.39.00.01
Subcategory Line Driver or Receivers
Technology BICMOS
Voltage - Supply 10.8V~13.2V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 12V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 75LBC786
JESD-30 Code R-PDSO-G28
Qualification Status Not Qualified
Power Supplies +-12V
Nominal Supply Current 70mA
Output Characteristics TOTEM-POLE
Differential Output NO
Output Polarity INVERTED
Protocol RS423
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 4/4
Driver Number of Bits 4
Receiver Number of Bits 4
Duplex Full
Receiver Hysteresis 40mV
Interface Standard EIA-423-B
Receive Delay-Max 1000 ns
Negative Supply Voltage-Nom -12V
Output Low Current-Max 0.004A
Out Swing-Min 8 V
High Level Input Current-Max 0.0001A
Dimensions
Height Seated (Max) 2.65mm
Length 17.9mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
