SN75LBC180ADRG4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 75LBC180 Tape & Reel (TR) RS422RS485 interface receiver 5V 15mA 120.003531mg 20ns
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 1251
Minimum: 1
-
+
Technical Details
Technical
Output Low Current-Max 0.008A
Supply Voltage1-Nom 5V
Simplex/Duplex Full Duplex
Receive Delay-Max 20 ns
Number of Transceivers 1
Interface Standard EIA-485-A; TIA-485-A; ISO 8482
Receiver Hysteresis 50mV
Duplex Full
Receiver Number of Bits 1
Driver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol RS422, RS485
Output Polarity COMPLEMENTARY
Differential Output YES
Output Characteristics DIFFERENTIAL
Data Rate 30Mbps
Logic Function Receiver
Nominal Supply Current 15mA
Number of Circuits 32
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 14
Base Part Number 75LBC180
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology BICMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Dimensions
Height 1.75mm
Length 8.65mm
Width 3.91mm
Thickness 1.58mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 120.003531mg
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
Alternative Model
