SN75C198DR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
3-STATE INVERTED ROHS3Compliant GATED Driver 0C~70C 300kbps 3500ns 8.65mm
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.6192
≥1 USD $1.6192
Inventory: 6985
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
High Level Input Current-Max 0.00001A
Out Swing-Min 8 V
Transmit Delay-Max 3500 ns
Negative Supply Voltage-Nom -12V
Number of Drivers 4
Interface Standard EIA-232-E; TIA-232-E; V.28
Dual Supply Voltage 12V
Min Dual Supply Voltage 4.5V
Number of Drivers/Receivers 4/0
Max Dual Supply Voltage 15V
Input Characteristics GATED
Protocol RS232
Output Polarity INVERTED
Differential Output NO
Output Characteristics 3-STATE
Data Rate 300 kbps
Nominal Supply Current 160μA
Pin Count 14
Base Part Number 75C198
Terminal Pitch 1.27mm
Supply Voltage 12V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~15V
Technology BIMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Driver
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
