SN75ALS163DWE4
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant SCHMITT TRIGGER GULL WING Half Transceiver 0C~70C 14ns 12.8mm 80mA
PDF
/
Inventory: 7893
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 12.8mm
Height Seated (Max) 2.65mm
Technical
Receive Delay-Max 14 ns
Interface Standard GENERAL PURPOSE
Receiver Hysteresis 650mV
Duplex Half
Receiver Number of Bits 8
Driver Number of Bits 8
Number of Drivers/Receivers 8/8
Input Characteristics SCHMITT TRIGGER
Protocol IEEE 488
Differential Output NO
Nominal Supply Current 80mA
Qualification Status Not Qualified
Pin Count 20
Base Part Number 75ALS163
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 8
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
HTS Code 8542.39.00.01
Additional Feature OPEN-COLLECTOR DRIVER OUTPUT OPTION AVAILABLE
Type Transceiver
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
