SN752232DGGR
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant SCHMITT TRIGGER GULL WING Full Transceiver 0C~70C 120kbps 250ns 223.195796mg
PDF
/
Buying Options
Total Price: USD $4.87
Unit Price: USD $4.87065
≥1 USD $4.87065
≥10 USD $3.99665
≥100 USD $3.8722
≥500 USD $3.7468
≥1000 USD $3.62235
Inventory: 5008
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Receivers 10
Supply Voltage1-Nom 9V
Transmit Delay-Max 500 ns
Negative Supply Voltage-Nom -9V
Receive Delay-Max 250 ns
Number of Transceivers 1
Number of Drivers 6
Interface Standard EIA-232-F; TIA-232-F; V.28
Receiver Hysteresis 500mV
Duplex Full
Number of Drivers/Receivers 3/5
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Data Rate 120 kbps
Logic Function Receiver, Transceiver
Nominal Supply Current 60mA
Operating Supply Voltage 4.6V
Pin Count 48
Base Part Number SN752232
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 6
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BIPOLAR
Subcategory Line Driver or Receivers
Type Transceiver
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Cut Tape (CT)
Operating Temperature 0°C~70°C
Physical
Weight 223.195796mg
Number of Pins 48
Package / Case 48-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
