SN75175DR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 SN75175 Cut Tape (CT) RS422RS423RS485 interface transceiver 5V 70mA 141.690917mg 35ns
PDF
/
Buying Options
Total Price: USD $1.87
Unit Price: USD $1.8744
≥1 USD $1.8744
≥10 USD $1.68168
≥100 USD $1.586816
≥500 USD $1.351944
≥1000 USD $1.269453
≥3000 USD $1.110754
Inventory: 2511
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature 0°C~70°C
Packaging Cut Tape (CT)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Receiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology BIPOLAR
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 1.27mm
Base Part Number SN75175
Pin Count 16
Operating Supply Voltage 5V
Power Supplies 5V
Operating Supply Current 70mA
Nominal Supply Current 70mA
Data Rate 10 Mbps
Output Characteristics 3-STATE
Differential Output NO
Output Polarity TRUE
Protocol RS422, RS423, RS485
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 0/4
Receiver Hysteresis 50mV
Number of Drivers 0
Receive Delay-Max 35 ns
Simplex/Duplex Half Duplex
Supply Voltage1-Nom 5V
Number of Receivers 4
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
