SN65MLVD207DR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
e4 65MLVD207 Tape & Reel (TR) LVDS Multipoint interface transceiver 3.3V 10muA 122.413241mg 6ns
PDF
/
Buying Options
Total Price: USD $3.85
Unit Price: USD $3.8532
≥1 USD $3.8532
≥10 USD $3.1616
≥100 USD $3.0628
≥500 USD $2.964
≥1000 USD $2.8652
Inventory: 1637
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Out Swing-Min 0.48 V
Number of Receivers 1
Output Low Current-Max 0.008A
Supply Voltage1-Nom 3.3V
Transmit Delay-Max 2.4 ns
Interface Standard EIA-899; TIA-899
Receiver Hysteresis 25mV
Duplex Full
Max Input Current 10μA
Driver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol LVDS, Multipoint
Output Polarity COMPLEMENTARY
Differential Output YES
Output Characteristics DIFFERENTIAL
Data Rate 200Mbps
Turn On Delay Time 6 ns
Propagation Delay 6 ns
Power Dissipation 950mW
Nominal Supply Current 24mA
Operating Supply Voltage 3.3V
Pin Count 14
Base Part Number 65MLVD207
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Max Power Dissipation 950mW
Subcategory Line Driver or Receivers
Type Transceiver
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 122.413241mg
Number of Pins 14
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
