SN65LVDS32BDG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 65LVDS32 Tube LVDS interface driver 3.3V 0.00001A 139.989945mg 6ns
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1650
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 139.989945mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series 65LVDS
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Receiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Power Dissipation 950mW
Technology BICMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Base Part Number 65LVDS32
Pin Count 16
Operating Supply Voltage 3.3V
Power Dissipation 950mW
Propagation Delay 6 ns
Supply Current-Max 23mA
Turn On Delay Time 6 ns
Data Rate 400Mbps
Differential Output NO
Protocol LVDS
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 0/4
Receiver Hysteresis 50mV
Supply Voltage1-Nom 3.3V
Number of Receivers 4
High Level Input Current-Max 0.00001A
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
