SN65LVDM320DGGRG4
RoHS
RoHS compliant
RoHS compliantPackage 64-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
R-PDSO-G48 65LVDM320 Tape & Reel (TR) LVDS interface receiver 3.3V 130mA 0.5mm 9.8ns
PDF
/
Inventory: 8464
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of Receivers 1
Transmit Delay-Max 8.7 ns
Receive Delay-Max 9.8 ns
Duplex Half
Driver Number of Bits 8
Number of Drivers/Receivers 8/8
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol LVDS
Differential Output YES
Data Rate 630 Mbps
Nominal Supply Current 130mA
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G48
Pin Count 48
Base Part Number 65LVDM320
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 3
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Type Transceiver
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 64
Package / Case 64-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
