SN65HVD35DG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 65HVD35 Tube RS422RS485 interface driver 3.3V 6.5mA 130.010913mg 70ns
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.288385
≥1 USD $2.288385
≥10 USD $1.975915
≥30 USD $1.780292
≥100 USD $1.579419
≥500 USD $1.488829
≥1000 USD $1.450755
Inventory: 1365
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm

Technical

Number of Receivers 1
Output Low Current-Max 0.06A
Supply Voltage1-Nom 3.3V
Transmit Delay-Max 305 ns
Simplex/Duplex Full Duplex
Receive Delay-Max 70 ns
Receiver Hysteresis 50mV
Duplex Full
Driver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol RS422, RS485
Output Polarity TRUE
Differential Output YES
Output Characteristics 3-STATE
Data Rate 5Mbps
Logic Function Receiver
Nominal Supply Current 6.5mA
Operating Supply Voltage 3.3V
Pin Count 14
Base Part Number 65HVD35
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Weight 130.010913mg
Number of Pins 14
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
