SN65HVD21DG4

Texas Instruments
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 Rail/Tube Nickel/Palladium/Gold (Ni/Pd/Au) Transceiver interface transceiver 5.5V 12mA 72.603129mg 50ns
PDF
/
Inventory: 3249
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Logic Function Transceiver
Nominal Supply Current 12mA
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 8
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Line Driver or Receivers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Rail/Tube
Number of Transmitters 1
Supply Voltage1-Nom 5V
Transmit Delay-Max 60 ns
Simplex/Duplex Half Duplex
Receive Delay-Max 50 ns
Receiver Number of Bits 1
Driver Number of Bits 1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Output Polarity COMPLEMENTARY
Differential Output YES
Output Characteristics 3-STATE
Data Rate 5 Mbps

Physical

Weight 72.603129mg
Number of Pins 8
Package / Case SOIC
Mount Surface Mount

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 3.91mm
Length 4.9mm
Height 1.58mm
