SN65HVD1781P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 65HVD1781 Tube RS422RS485 interface receiver 5V 6mA 523.190449mg 200ns
PDF
/
Buying Options
Total Price: USD $33.13
Unit Price: USD $33.126829
≥1 USD $33.126829
≥10 USD $31.251723
≥100 USD $29.48276
≥500 USD $27.813929
≥1000 USD $26.239552
Inventory: 1509
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 9.81mm
Height 5.08mm
Technical
Supply Voltage1-Nom 5V
Simplex/Duplex Half Duplex
Number of Transceivers 1
Receiver Hysteresis 50mV
Duplex Half
Receiver Number of Bits 1
Driver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol RS422, RS485
Output Polarity DIFFERENTIAL
Differential Output YES
Output Characteristics DIFFERENTIAL
Data Rate 1Mbps
Propagation Delay 200 ns
Operating Supply Current 6mA
Operating Supply Voltage 5V
Pin Count 8
Base Part Number 65HVD1781
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 3.15V~5.5V
Max Power Dissipation 976mW
Subcategory Line Driver or Receivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 523.190449mg
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
