SN65EL16DR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant DIFFERENTIAL GULL WING Receiver Receiver -40C~85C +-5V 4Gbps 0.3ns
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.5922
≥1 USD $1.5922
≥10 USD $1.30625
≥100 USD $1.2654
≥500 USD $1.22455
≥1000 USD $1.18465
Inventory: 1105
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Number of Receivers 1
Transmit Delay-Max 0.3 ns
Negative Supply Voltage-Nom -5V
Receive Delay-Max 0.3 ns
Interface Standard GENERAL PURPOSE
Number of Drivers/Receivers 0/1
Input Characteristics DIFFERENTIAL
Differential Output YES
Data Rate 4 Gbps
Nominal Supply Current 23mA
Power Supplies +-5V
Pin Count 8
Base Part Number 65EL16
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.2V~5.7V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Receiver
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
