SN65ALS1176P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant DIFFERENTIAL SCHMITT TRIGGER Half Transceiver Transceiver -25C~85C 5V 35Mbd 25ns
PDF
/
Buying Options
Total Price: USD $3.08
Unit Price: USD $3.0818
≥1 USD $3.0818
≥10 USD $2.5289
≥100 USD $2.45005
≥500 USD $2.3712
≥1000 USD $2.2914
Inventory: 26010
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Technical
High Level Input Current-Max 0.00002A
Receive Delay-Max 25 ns
Number of Drivers 1
Receiver Hysteresis 60mV
Duplex Half
Receiver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol RS422, RS485
Differential Output YES
Data Rate 35Mbd
Nominal Supply Current 30mA
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 8
Base Part Number 65ALS1176
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology BIPOLAR
Subcategory Line Driver or Receivers
Type Transceiver
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature -25°C~85°C
Physical
Weight 440.409842mg
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
