MAX3243EIPWRE4
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 MAX3243 Tape & Reel (TR) RS232 interface receiver 5V 1mA 117.508773mg 500kbps
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.287955
≥1 USD $1.287955
≥200 USD $0.498902
≥500 USD $0.481834
≥1000 USD $0.472644
Inventory: 1171
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Number of Pins 28
Weight 117.508773mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Transceiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 3
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX3243
Pin Count 28
Qualification Status Not Qualified
Operating Supply Voltage 5V
Nominal Supply Current 1mA
Logic Function Receiver
Data Rate 500kbps
Differential Output NO
Output Polarity INVERTED
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 3/5
Duplex Full
Receiver Hysteresis 500mV
Number of Drivers 3
Number of Transceivers 1
Supply Voltage1-Nom 5V
Number of Receivers 5
Out Swing-Min 5 V
Dimensions
Height 1.2mm
Length 9.7mm
Width 4.4mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
