MAX3243ECDW
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 MAX3243 Tube RS232 interface receiver 5V 1mA 730.794007mg 150ns
PDF
/
Buying Options
Total Price: USD $2.51
Unit Price: USD $2.508
≥1 USD $2.508
≥10 USD $2.2506
≥100 USD $2.12784
≥500 USD $1.84404
≥1000 USD $1.74951
Inventory: 336
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Weight 730.794007mg
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Transceiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Line Driver or Receivers
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 3
Supply Voltage 3.3V
Base Part Number MAX3243
Pin Count 28
Output Voltage 5V
Operating Supply Voltage 5V
Number of I/O 16
Nominal Supply Current 1mA
Propagation Delay 150 ns
Logic Function Receiver, Transceiver
Data Rate 500kbps
Differential Output NO
Output Polarity INVERTED
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 3/5
Duplex Full
Receiver Hysteresis 500mV
Number of Drivers 3
Number of Transceivers 1
Simplex/Duplex Full Duplex
Supply Voltage1-Nom 5V
Number of Receivers 5
Out Swing-Min 5 V
Dimensions
Height 2.65mm
Length 17.9mm
Width 7.5mm
Thickness 2.35mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
