MAX3223EIPWR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 MAX3223 Tape & Reel (TR) ALSO OPERATES AT 5V SUPPLY interface receiver 500mV 1mA 76.997305mg 150ns
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $2.32496
≥100 USD $2.19296
≥500 USD $1.868504
≥1000 USD $1.754509
≥3000 USD $1.535178
Inventory: 1463
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Number of Pins 20
Weight 76.997305mg

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Supply Voltage1-Nom 3.3V
Simplex/Duplex Full Duplex
ESD Protection Yes
Number of Transceivers 1
Number of Drivers 2
Receiver Hysteresis 500mV
Duplex Full
Receiver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Output Polarity INVERTED
Differential Output NO
Data Rate 500kbps
Logic Function Receiver, Transceiver
Propagation Delay 150 ns
Nominal Supply Current 1mA
Number of I/O 8
Power Supplies 3.3/5V
Pin Count 20
Base Part Number MAX3223
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology CMOS
Subcategory Line Driver or Receivers
Additional Feature ALSO OPERATES AT 5V SUPPLY
Type Transceiver
ECCN Code EAR99
Number of Terminations 20

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Thickness 1mm
Width 4.4mm
Length 6.5mm
Height 1.2mm
