MAX232EIDWRG4

Texas Instruments
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 SOIC Nickel/Palladium/Gold (Ni/Pd/Au) Receiver interface transceiver 5V 10mA 420.395078mg 250kbps
PDF
/
Inventory: 6186
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case SOIC
Number of Pins 16
Weight 420.395078mg

Technical

JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Pin Count 16
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Nominal Supply Current 10mA
Logic Function Receiver
Data Rate 250 kbps
Differential Output NO
Output Polarity INVERTED
Input Characteristics SCHMITT TRIGGER
Interface IC Type LINE TRANSCEIVER
Driver Number of Bits 2
Number of Transceivers 1
Supply Voltage1-Nom 5V
Number of Receivers 2

Dimensions

Width 7.5mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
