MAX232ECN
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 MAX232 Tube RS232 interface receiver 5V 10mA 955.690774mg 250kbps
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.7334
≥1 USD $0.7334
≥10 USD $0.60135
≥100 USD $0.5833
≥500 USD $0.5643
≥1000 USD $0.5453
Inventory: 1631
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 19.3mm
Height 5.08mm
Technical
Supply Voltage1-Nom 5V
Simplex/Duplex Full Duplex
ESD Protection Yes
Number of Transceivers 1
Number of Drivers 2
Receiver Hysteresis 500mV
Duplex Full
Receiver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Output Polarity INVERTED
Differential Output NO
Data Rate 250kbps
Logic Function Receiver, Transceiver
Max Supply Current 10mA
Nominal Supply Current 10mA
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 16
Base Part Number MAX232
Supply Voltage 5V
Number of Functions 2
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Subcategory Line Driver or Receivers
Type Transceiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 955.690774mg
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
