MAX213IDB
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 MAX213 Tube RS232 interface transceiver 5V 20mA 208.397344mg 120Kbps
PDF
/
Buying Options
Total Price: USD $2.66
Unit Price: USD $2.6576
≥1 USD $2.6576
≥10 USD $2.39008
≥100 USD $2.25984
≥500 USD $1.95844
Inventory: 163
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 10.2mm
Height 2mm
Technical
Out Swing-Min 2 V
Number of Receivers 5
Supply Voltage1-Nom 5V
Number of Transceivers 1
Number of Drivers 4
Receiver Hysteresis 500mV
Duplex Full
Number of Drivers/Receivers 4/5
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Output Polarity TRUE
Differential Output NO
Data Rate 120Kbps
Logic Function Receiver, Transceiver
Output Current 10mA
Nominal Supply Current 20mA
Power Supplies 5V
Operating Supply Voltage 5V
Output Voltage 9V
Qualification Status Not Qualified
Pin Count 28
Base Part Number MAX213
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Subcategory Line Driver or Receivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 208.397344mg
Number of Pins 28
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
