LMS1485IM/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant DIFFERENTIAL SCHMITT TRIGGER GULL WING Half Transceiver -40C~85C 5V 30Mbps 55ns
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.657763
≥1 USD $0.657763
≥200 USD $0.254703
≥500 USD $0.246825
≥1000 USD $0.241574
Inventory: 1643
Minimum: 1
-
+
Technical Details
Technical
Power Supplies 5V
Supply Current-Max 2.2mA
Data Rate 30Mbps
Differential Output YES
Protocol RS422, RS485
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 1/1
Driver Number of Bits 1
Receiver Number of Bits 1
Duplex Half
Receiver Hysteresis 70mV
Interface Standard EIA-422-B; TIA-422-B; EIA-485-A; TIA-485-A; V.11; X.27
Receive Delay-Max 55 ns
Transmit Delay-Max 20 ns
Output Low Current-Max 0.004A
Out Swing-Min 1.5 V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number LMS1485
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology BICMOS
Subcategory Line Driver or Receivers
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type Transceiver
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height Seated (Max) 1.753mm
Length 4.902mm
Width 3.899mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
