ISO1452BDWR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description R-PDSO-G16 ISO1452 Tape & Reel (TR) RS422RS485 interface transceiver 30mV 10.3mm 60ns 50Mbps
PDF
/
Buying Options
Total Price: USD $12.08
Unit Price: USD $12.0821
≥1 USD $12.0821
≥10 USD $9.91325
≥100 USD $9.60355
≥500 USD $9.29385
≥1000 USD $8.98415
Inventory: 1519
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 7.5mm
Length 10.3mm
Height Seated (Max) 2.65mm

Technical

Supply Voltage1-Nom 5V
Transmit Delay-Max 41 ns
Receive Delay-Max 60 ns
Interface Standard EIA-485-A; TIA-485-A; EIA-422
Receiver Hysteresis 30mV
Duplex Full
Receiver Number of Bits 1
Driver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol RS422, RS485
Differential Output YES
Data Rate 50Mbps
JESD-30 Code R-PDSO-G16
Base Part Number ISO1452
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.71V~1.89V 2.25V~5.5V 3V~5.5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver, Isolated
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA

Physical

Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 6 Weeks
