GD65232DBR
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant SCHMITT TRIGGER GULL WING Full Transceiver -40C~85C 120Kbps 156.687814mg 0.00001A
PDF
/
Buying Options
Total Price: USD $1.3
Unit Price: USD $1.300838
≥1 USD $1.300838
≥10 USD $1.227205
≥100 USD $1.157737
≥500 USD $1.09221
≥1000 USD $1.030382
Inventory: 1154
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 7.2mm
Height Seated (Max) 2mm
Technical
High Level Input Current-Max 0.00001A
Out Swing-Min 12 V
Number of Receivers 5
Output Low Current-Max 0.01A
Supply Voltage1-Nom 9V
Negative Supply Voltage-Nom -9V
Number of Drivers 3
Receiver Hysteresis 500mV
Duplex Full
Number of Drivers/Receivers 3/5
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Data Rate 120Kbps
Nominal Supply Current 38mA
Qualification Status Not Qualified
Pin Count 20
Base Part Number GD65232
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 3
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V ±7.5V~15V
Technology BIPOLAR
Subcategory Line Driver or Receivers
Additional Feature EASY INTERFACE BETWEEN UART, SERIAL-PORT CONNECTOR OF IBM PC/AT
Type Transceiver
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series GD
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 156.687814mg
Number of Pins 20
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
