DS92LV010ATMX
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
e0 DS92LV010 Tape & Reel (TR) LVDS interface receiver 3.3V 0.002A 1.75mm 12ns
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.4168
≥1 USD $2.4168
≥10 USD $1.98265
≥100 USD $1.9209
≥500 USD $1.85915
≥1000 USD $1.7974
Inventory: 1500
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Output Low Current-Max 0.002A
Supply Voltage1-Nom 3.3V
Transmit Delay-Max 5 ns
Number of Drivers 1
Interface Standard GENERAL PURPOSE
Duplex Half
Receiver Number of Bits 1
Number of Drivers/Receivers 1/1
Power Consumption 53W
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol LVDS
Output Polarity COMPLEMENTARY
Differential Output YES
Output Characteristics DIFFERENTIAL
Data Rate 100Mbps
Turn On Delay Time 12 ns
Supply Current-Max 25mA
Propagation Delay 12 ns
Power Dissipation 1.025W
Power Supplies 3.3/5V
Operating Supply Voltage 3.3V
Pin Count 8
Base Part Number DS92LV010
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology CMOS
Max Power Dissipation 1.025W
Subcategory Line Driver or Receivers
Terminal Finish Tin/Lead (Sn/Pb)
Type Transceiver
Number of Terminations 8
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
