DS91M047TMAX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
5A991.B.1 DS91M047 Tape & Reel (TR) LVDS Multipoint interface receiver 3.3V 0.000015A 1.75mm 5ns
PDF
/
Buying Options
Total Price: USD $2.98
Unit Price: USD $2.9832
≥1 USD $2.9832
Inventory: 1330
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code 5A991.B.1
Type Driver
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 2.21W
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Base Part Number DS91M047
Pin Count 16
Operating Supply Voltage 3.3V
Number of Elements 4
Power Dissipation 2.21W
Propagation Delay 5 ns
Turn On Delay Time 5 ns
Data Rate 250Mbps
Output Characteristics 3-STATE
Differential Output YES
Output Polarity TRUE
Protocol LVDS, Multipoint
Input Characteristics STANDARD
Power Consumption 215W
Number of Drivers/Receivers 4/0
Driver Number of Bits 4
Interface Standard EIA-899; TIA-899
Supply Voltage1-Nom 3.3V
High Level Input Current-Max 0.000015A
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
