DS91D176TMAX
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
Non-RoHS Compliant DIFFERENTIAL GULL WING Half interface receiver -40C~85C 833mW 200Mbps 7.5ns
PDF
/
Buying Options
Total Price: USD $2.07
Unit Price: USD $2.071
≥1 USD $2.071
≥10 USD $1.69955
≥100 USD $1.64635
≥500 USD $1.59315
≥1000 USD $1.53995
Inventory: 1113
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Number of Drivers 1
Duplex Half
Receiver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics DIFFERENTIAL
Protocol LVDS
Differential Output YES
Data Rate 200Mbps
Turn On Delay Time 7.5 ns
Propagation Delay 7.5 ns
Operating Supply Voltage 3.3V
Pin Count 8
Base Part Number DS91D176
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Max Power Dissipation 833mW
Subcategory Line Driver or Receivers
Terminal Finish Tin/Lead (Sn/Pb)
Type Transceiver
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
