DS90LV027AHM

Texas Instruments
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description Non-RoHS Compliant STANDARD GULL WING Driver interface transceiver -40C~125C 1.19W 600Mbps 2ns
PDF
/
Buying Options
Total Price: USD $2.25
Unit Price: USD $2.2515
≥1 USD $2.2515
≥10 USD $1.8468
≥100 USD $1.7898
≥500 USD $1.73185
≥1000 USD $1.6739
Inventory: 1530
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm

Technical

High Level Input Current-Max 0.00001A
Number of Drivers 2
Interface Standard EIA-644; TIA-644
Number of Drivers/Receivers 2/0
Input Characteristics STANDARD
Protocol LVDS
Differential Output YES
Data Rate 600Mbps
Turn On Delay Time 2 ns
Propagation Delay 2 ns
Operating Supply Voltage 3.3V
Pin Count 8
Base Part Number DS90LV027
Supply Voltage 3.3V
Number of Functions 2
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Max Power Dissipation 1.19W
Terminal Finish Tin/Lead (Sn/Pb)
Type Driver
ECCN Code 5A991.B.1
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C

Physical

Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
