DS26LV31TMX
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 DS26LV31 Tape & Reel (TR) RS422RS485 interface driver 3.3V 0.00001A 9.9mm -40C~85C
PDF
/
Buying Options
Total Price: USD $3.02
Unit Price: USD $3.0177
≥1 USD $3.0177
≥10 USD $2.84689
≥100 USD $2.68574
≥500 USD $2.53372
≥1000 USD $2.3903
≥3000 USD $2.255
Inventory: 29667
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Driver
Terminal Finish Tin/Lead (Sn/Pb)
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 235
Number of Functions 4
Supply Voltage 3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number DS26LV31
Pin Count 16
Operating Supply Voltage 3.3V
Nominal Supply Current 100μA
Output Characteristics 3-STATE
Differential Output YES
Protocol RS422, RS485
Input Characteristics STANDARD
Number of Drivers/Receivers 4/0
Number of Drivers 4
Out Swing-Min 2 V
High Level Input Current-Max 0.00001A
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
