DS2003TMX
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 DS2003 Tape & Reel (TR) LOGIC LEVEL COMPATIBLE interface transceiver 50V 500mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 1374
Minimum: 1
-
+
Technical Details
Technical
Number of Drivers/Receivers 6/0
Collector Emitter Saturation Voltage 1.6V
Emitter Base Voltage (VEBO) 6V
Collector Current-Max (IC) 0.5A
Turn Off Time-Max (toff) 1000ns
Turn On Time-Max (ton) 1000ns
JEDEC-95 Code MS-012AC
Collector Emitter Voltage (VCEO) 55V
Transistor Application SWITCHING
Output Current 500mA
Configuration COMPLEX
Polarity NPN
Number of Elements 7
Output Voltage 50V
Number of Outputs 7
Pin Count 16
Base Part Number DS2003
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V
HTS Code 8542.39.00.01
Additional Feature LOGIC LEVEL COMPATIBLE
Terminal Finish Tin/Lead (Sn/Pb)
Type Driver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Transistor Element Material SILICON
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
