AM26LS32ACPWRG4
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
3-STATE TRUE RoHS Compliant DIFFERENTIAL SCHMITT TRIGGER interface transceiver 70C 5V 10Mbps 35ns
PDF
/
Inventory: 5749
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 5mm
Height Seated (Max) 1.2mm
Technical
Number of Receivers 4
Supply Voltage1-Nom 5V
Receive Delay-Max 35 ns
ESD Protection No
Number of Drivers 0
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Output Polarity TRUE
Differential Output NO
Output Characteristics 3-STATE
Data Rate 10 Mbps
Logic Function Receiver
Max Supply Current 70mA
Nominal Supply Current 70mA
Temperature Grade COMMERCIAL
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 16
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Min Operating Temperature 0°C
Max Operating Temperature 70°C
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Physical
Weight 61.887009mg
Number of Pins 16
Surface Mount YES
Package / Case TSSOP
Contact Plating Gold
