AM26LS32ACDR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 AM26LS32 Tape & Reel (TR) RS422RS423 interface receiver 5V 70mA 141.690917mg 35ns
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.50072
≥100 USD $0.470624
≥500 USD $0.383944
≥1000 USD $0.356646
≥3000 USD $0.303547
Inventory: 1640
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm
Technical
Number of Receivers 4
Supply Voltage1-Nom 5V
Receive Delay-Max 35 ns
ESD Protection No
Number of Drivers 0
Receiver Hysteresis 50mV
Number of Drivers/Receivers 0/4
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol RS422, RS423
Output Polarity TRUE
Differential Output NO
Output Characteristics 3-STATE
Data Rate 10 Mbps
Max Supply Current 70mA
Nominal Supply Current 70mA
Operating Supply Current 70mA
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 16
Base Part Number AM26LS32
Current Rating 8A
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology BIPOLAR
Type Receiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Weight 141.690917mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
