AM26C32CDBR
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 AM26C32 Tape & Reel (TR) RS422RS423 interface receiver 60mV 2mm 27ns 0C~70C TA
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 1515
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 6.2mm
Height 2mm
Technical
Supply Voltage1-Nom 5V
Receive Delay-Max 27 ns
Interface Standard V.10; V.11; EIA-422-B; EIA-423-B
Receiver Hysteresis 60mV
Receiver Number of Bits 1
Number of Drivers/Receivers 0/4
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Protocol RS422, RS423
Differential Output NO
Qualification Status Not Qualified
Base Part Number AM26C32
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BICMOS
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Receiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
