ST75C185BDR

STMicroelectronics
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 ST75C Cut Tape (CT) RS232 interface transceiver -12V 4000ns 0C~70C
PDF
/
Inventory: 9236
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Technical

Number of Transmitters 3
Number of Receivers 5
Supply Voltage1-Nom 12V
Transmit Delay-Max 4000 ns
Negative Supply Voltage-Nom -12V
Receive Delay-Max 4000 ns
Number of Transceivers 1
Receiver Hysteresis 1.1V
Duplex Full
Driver Number of Bits 3
Number of Drivers/Receivers 3/5
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Logic Function Receiver
Pin Count 20
Base Part Number ST75C
Supply Voltage 5V
Number of Functions 3
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Cut Tape (CT)
Operating Temperature 0°C~70°C

Physical

Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
