ST485EBDR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 ST485 Cut Tape (CT) RS422RS485 interface transceiver 5V 300muA 1.75mm 45ns
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.82544
≥100 USD $0.783552
≥500 USD $0.64372
≥1000 USD $0.601744
≥3000 USD $0.531784
Inventory: 1475
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Type Transceiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Line Driver or Receivers
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ST485
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Interface RS-422, RS-485
Nominal Supply Current 300μA
Data Rate 5Mbps
Differential Output YES
Protocol RS422, RS485
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 1/1
Driver Number of Bits 1
Duplex Half
Receiver Hysteresis 70mV
Simplex/Duplex Half Duplex
Transmit Delay-Max 45 ns
Output Low Current-Max 0.004A
Number of Receivers 1
Dimensions
Height 1.75mm
Length 5mm
Width 4mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
