ST3232EBWR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 ST3232 Cut Tape (CT) RS232 interface driver 13.2V 300muA 7.5mm 250kbps
PDF
/
Inventory: 8943
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 7.5mm

Technical

Number of Receivers 2
Number of Transceivers 1
Receiver Hysteresis 500mV
Duplex Full
Driver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Data Rate 250kbps
Nominal Supply Current 300μA
Interface RS-232
Power Supplies 3.3/5V
Output Voltage 13.2V
Qualification Status Not Qualified
Pin Count 16
Base Part Number ST3232
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Subcategory Line Driver or Receivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C

Physical

Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
