ST26C32ABDR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 ST26C32 Cut Tape (CT) RS422RS423 interface receiver 5V 23mA 1.65mm 30ns
PDF
/
Buying Options
Total Price: USD $1.78
Unit Price: USD $1.7776
≥1 USD $1.7776
≥10 USD $1.59632
≥100 USD $1.506208
≥500 USD $1.283392
≥1000 USD $1.205037
≥3000 USD $1.054398
Inventory: 5491
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16

Technical

Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Type Receiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ST26C32
Pin Count 16
Operating Supply Voltage 5V
Power Supplies 5V
Number of Channels 4
Interface RS-422
Nominal Supply Current 23mA
Data Rate 20Mbps
Differential Output NO
Protocol RS422, RS423
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 0/4
Receiver Number of Bits 4
Receiver Hysteresis 60mV
Receive Delay-Max 30 ns
Output Low Current-Max 0.006A

Dimensions

Height 1.65mm
Length 10mm
Width 4mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
